Pin Gauges Sets – 0.025 mm increment
Precision pin gauge sets with 0.025mm increment, 4 standard sets cover a range of diameters 0.3 to 12.525mm. Pin tolerance is +0.002/+0.005 mm or -0.002/-0.005 mm, select plus or minus tolerance when placing an order. Standard sets offer great value and are supplied in a well labelled case. Gauge pins are manufactured from hardened tool steel to ensure long life and are supplied with a manufacturers certificate of conformance (COC).
Product options
Universal handles
Note set cases are either timber or plastic.
Applicable standards
Manufactures specification
Why this product is used
Pin gauge sets are a great way to check hole diameters quickly. Select a set with a range and increments to suit your products. An optional universal handle can be used to setup a Go/Nogo style plug gauge, then disassembled after use.
Downloads
-
Customisation
Customisation is offered on most gauges. We can add a new feature to a standard gauge, manufacture a revised design based on a standard gauge, or design a new gauge to suit your application.
-
Delivery
We offer express or economy delivery and can send products to local, interstate and overseas locations. We’re also happy to use your own delivery supplier.
-
Manufacturing
We are an Australian business located in Airport West Victoria. Quality is a priority and we have ISO 9001 and ISO 17025 management systems in place.
Specifications
| Set Type | Range / Increment | Stock Status |
|---|---|---|
| PG-0 Tol. 0.002/0.005 mm Plus or Minus | 0.300 – 1.525 mm / 0.025 mm | Available to order |
| PG-1 Tol. 0.002/0.005 mm Plus or Minus | 1.550 – 6.275 mm / 0.025 mm | Available to order |
| PG-2A Tol. 0.002/0.005 mm Plus or Minus | 6.300 – 9.775 mm / 0.025 mm | Available to order |
| PG-2B Tol. 0.002/0.005 mm Plus or Minus | 9.800 – 12.525 mm / 0.025 mm | Available to order |
| PG-2C Tol. 0.002/0.005 mm Plus or Minus | 12.550 – 12.975 mm / 0.025 mm | Available to order |
| Custom | Made to Order |
FAQs
How do I calibrate my gauge set?
One common method is to label the pin gauge set “calibrate before use” then have a calibrated micrometer available to check pins prior to use.
Can a pin gauge set be made to my own specification?
Yes, we can make up sets as required, class X, Z or ZZ are available.
